Flexible Lip Seal-LS226
Designed for low-speed, low-precision agitator applications in compliance with API 682 and Derui corporate standards.It is rated for a pressure of up to 0.4 MPa.
Typical Applications:
Designed for agitators handling acidic/alkaline process media in food, pharmaceutical and cosmetic industries.
Mediums:
Suitable for acidic and alkaline process fluids across industrial applications.
Performance Capabilities:
Pressure: 0~ 0.4 MPa
Temperature: -20 ~200°C
Linear Speed: ≤5 m/s
Material Selection:
Metallic Components: 304, 316L, 2507、TA2
Seal Rings: PTFE、PPS、PEEK
Elastomer Options: FKM, FFKM, EPDM, NBR,AFLAS
-
Technical Features:
1.Suitable for low-speed rotating equipment with relaxed alignment and precision requirements.
2.Radial contact design with face contact configuration, featuring multiple seal ring assemblies to prevent media leakage and enhance sealing performance.
3.Precision-engineered with a range of high-performance materials to ensure reliable sealing across diverse operating environments.
4.Barrier gas sealing system for absolute leakage prevention.
5.Bearing-Integrated design for enhanced load capacity and operational precision.
6.The highly reliable drive design effectively prevents slippage even on high-hardness shafts.
Solution Selection:
Requires integration with a barrier gas sealing system ,customizable multiple seal ring configurations for different operating conditions.Designed for DEREI’s GCS74 dry gas seal support system to ensure stable sealing performance. Customization is available based on user application and requirements.
